1.采用直齒齒輪傳動，經過滲碳淬火處理，齒向齒闊修行處理，表面噴砂鍍鎳，設備運行平穩，噪音小。 2.結構簡單，交貨期快，可大批量生產。 3.減速機種類齊全......
0510-85167909
產品 · 簡介
TAE系列性能表 / TAE Series Performance Table | ||||||||
規格 Specification | 單位 Unit | 節數 Stage | 減速比 Ratio | TAE070 | TAE090 | TAE120 | TAE155 | TAE205 |
額定輸出力矩 Rated output torque T2N | Nm | 1 | 3 | 55 | 130 | 208 | 342 | 588 |
4 | 50 | 140 | 290 | 542 | 1050 | |||
5 | 60 | 160 | 330 | 650 | 1200 | |||
6 | 55 | 150 | 310 | 600 | 1100 | |||
7 | 50 | 140 | 300 | 550 | 1100 | |||
8 | 45 | 120 | 260 | 500 | 1000 | |||
10 | 40 | 100 | 230 | 450 | 900 | |||
2 | 15 | 55 | 130 | 208 | 342 | 588 | ||
20 | 50 | 140 | 290 | 542 | 1050 | |||
25 | 60 | 160 | 330 | 650 | 1200 | |||
30 | 55 | 150 | 310 | 600 | 1100 | |||
35 | 50 | 140 | 300 | 550 | 1100 | |||
40 | 45 | 120 | 260 | 500 | 1000 | |||
50 | 60 | 160 | 330 | 650 | 1200 | |||
60 | 55 | 150 | 310 | 600 | 1100 | |||
70 | 50 | 140 | 300 | 550 | 1100 | |||
80 | 45 | 120 | 260 | 500 | 1000 | |||
100 | 40 | 100 | 230 | 450 | 900 | |||
急停扭矩 /Emergency stop torque T2NOT | Nm | 1.2 | 3-100 | 三倍額定輸出力矩/Triple rated output torque | ||||
額定輸入轉速/Rated input speed η1N | rpm | 1,2 | 3-100 | 5000 | 4000 | 4000 | 3000 | 3000 |
******輸入轉速/Maximum input speed η1B | 1,2 | 3-100 | 10000 | 8000 | 8000 | 6000 | 6000 | |
扭轉剛性 /Torsional rigidity | Nm/arcmin | 1,2 | 3-100 | 7 | 14 | 25 | 50 | 145 |
容許徑向力 /Allowable radial force F2aB | N | 1,2 | 3-100 | 1530 | 3250 | 6700 | 9400 | 14500 |
容許軸向力/Allowable axial force F2aB | N | 1,2 | 3-100 | 765 | 1625 | 3350 | 4700 | 7250 |
使用壽命/Lifespan | hr | 1,2 | 3-100 | 20000 | ||||
效率 /Efficiency | % | 3?10 | ≥97% | |||||
2 | 15-100 | ≥94% | ||||||
重量 /Weight | kg | 3~10 | 1.4 | 3.7 | 8 | 16 | 36 | |
2 | 15-100 | 1.6 | 4.2 | 8.9 | 17 | 37 | ||
使用溫度 /Working temperature | °C | 1,2 | 3-100 | -10°C~90°C | ||||
潤滑 /Lubricating | 1,2 | 合成潤滑油脂 /Synthetic lubricating grease | ||||||
防護等級/IP Grade | 1,2 | 3-100 | IP65 | |||||
安裝方向 /Installation direction | 1,2 | 3-100 | 任意方向/In any direction | |||||
噪音值(η1 =3000rpm,無負載) Noise level (η1 =3000rpm,off load) | dB(A) | 1,2 | 3-100 | ≤58 | ≤60 | ≤63 | ≤65 | ≤67 |
